Disadvantages of Microchannel Condensers in Chillers and HVAC Equipment

Introduction

Microchannel condensers have become a standard solution in small and medium capacity air chillers in recent years. The reason for their proliferation is obvious: reduced size and weight of the units, reduced refrigerant charge, increased specific heat transfer. Manufacturers such as Trane, Johnson Controls, Daikin, Climaveneta have been actively integrating microchannel heat exchangers into their product lines in an effort to optimise the efficiency and cost of equipment.

However, adopting such technology is not an unambiguous improvement. Despite the obvious advantages, microchannel condensers have a number of engineering limitations that directly affect operational reliability, maintainability and system behaviour under real-world conditions. They differ from traditional copper-aluminium heat exchangers not only in geometry, but also in heat exchange principles, refrigerant circulation modes, mechanical strength and nature of corrosion processes.

The initial application of microchannel heat exchangers is automotive air conditioners, where operating pressures are lower and operating cycles are shorter. In HVAC-systems operating on R410A or R32 – condensation pressure is higher, and operating modes are longer. In such conditions typical problems appear: increased sensitivity to contamination, risk of local clogging of microchannels, higher probability of microcracks in the soldering zone of collectors, higher requirements to the quality of service operations.

Take a look at our catalogue of chillers and heat pumps –only proven models from reliable manufacturers, with full technical specifications and adaptation to your conditions for various applications.

Design features of the microchannel heat exchanger

The heat exchanger consists of three main elements: extruded channel plates, fins between them and two collectors

Fig. 1 – Design of a microchannel heat exchanger

Between the refrigerant tubes are fins profiled to increase heat transfer. Traditional tubular and finned heat exchangers are mechanically expanded without actual contact between the tubes and the fins. Aluminium brazed heat exchangers, on the other hand, have perfect continuous contact between the tubes and fins, ensuring efficient heat transfer.

Figure 2 – Microchannel tube ribbing

The thickness of the channel plate is only 1.3 mm and the channel diameter is 0.79 mm. This results in a maximum heat transfer surface with a small product size.

Fig. 3 – Section of a microchannel tube

Due to their small hydraulic diameter, microchannel aluminium tubes transfer heat more efficiently than traditional round copper tubes. The cold agent tube is flat with many parallel microchannels.

The heat exchanger is brazed in an oven with a nitrogen environment.

Fig. 4 – Heat exchanger brazing process

Advantages of microchannel heat exchangers

The main advantages of microchannel heat exchangers are much smaller size, weight and cost. For example, while tubular-ribbed devices use copper tubes and aluminium fins, microchannel devices are made of aluminium only, which is known to be a cheaper and lighter metal.

The use of microchannel condensers allows an average 55% reduction in the heat exchange surface area. Microchannel condensers also allow to reduce the refrigerant capacity of the refrigeration system, because at the same capacity they have 50-70% smaller internal volume.

Fig.5 – Comparison of heat exchange surface area of microchannel and standard copper-aluminium air condensers

Fig. 6 – Comparison of the internal volume of microchannel and standard air condensers

Due to the smaller thickness of the microchannel units, the air pressure loss is 50 % lower, which means that less powerful fans with lower energy consumption can be used.

Disadvantages of microchannel heat exchangers

Despite their high specific efficiency and reduced material consumption, microchannel condensers have a number of design and operating limitations that fundamentally distinguish their behaviour from conventional copper-aluminium heat exchangers. These limitations manifest themselves in refrigerant and oil circulation, pressure behaviour, corrosion resistance and maintainability. As a result, the operation of equipment with microchannel condensers requires more stringent service requirements.

If you are unsure about your choice of chiller or heat pump, please contact our experts for technical advice and professional selection of equipment for your application.

Problems with refrigerant distribution

In traditional tube condensers, the 7-9 mm diameter allows for a significant reserve of capacity, while the microchannel operates with virtually no reserve. The oil dissolved in the refrigerant moves along the microchannel in the form of a thin film, and any deviation from the laminar distribution – pressure jump, temperature difference, deterioration of oil quality – creates preconditions for local overflow or stagnant zones. These effects become more pronounced in partial load operation, which is especially critical for chillers with inverter compressors, where the refrigerant mass flow rate varies over a wide range.

Sensitivity to contamination

The density of fins and small fin thickness increases the heat transfer surface, but makes the heat exchanger more prone to accumulation of dust and biological fouling. Cleaning a microchannel apparatus requires low water pressure, strict jet direction and extra care, as the fins are easily deformed. Practice shows that rib damage leads not only to localised deterioration of aerodynamics, but also to the risk of deformation of the plate tube, which is unacceptable due to the thin-walled construction.

Fig.7 – Typical fouling spot, extremely difficult to clean and “eating” the heat exchanger surface

Mechanical strength

The third factor is the limited mechanical strength of the microchannel tube to manifold connection area. This is the area most likely to leak, with oil stains appearing in the solder area.

Fig. 8 – Oil stains indicate refrigerant leakage

Fig 9. – The most likely place of leakage is at the pipe and manifold connection

Microchannel heat exchangers were originally developed as a replacement for traditional copper-aluminium units for moderately pressurised refrigerants (R-134a, analogues). Many early solutions were designed for these pressures and the operating tolerances of the time. When R-410A came on the market en masse (and became the standard for residential/commercial HVAC systems), manufacturers either supplied reinforced versions or reverted to designs with thicker walls and/or reinforced manifolds. But not all manufacturers switched to “universal” reinforced units right away, as it adds mass, complexity and cost.

Thin “flat” ducts minimise refrigerant volume and give high heat transfer, but they are themselves susceptible to local stresses from pressure (wall bulging, metal fatigue). The problem is usually not in the thin plate itself, but in the transition “channel – manifold/nozzle”. The solder joints become stress concentrators, where the risk of leakage and/or fatigue failure at high operating pressures is significantly higher.

Table 1. Comparison of condensation pressures of some refrigerants.

Corrosion

The corrosion resistance of aluminium is not absolute, and the frequent claim of “stainless aluminium” misleads engineers. Aluminium is indeed protected by an oxide film, but this film is only stable under moderately neutral conditions. A pH deviation from the 4.5-8.5 range, the presence of salts or alkalis, or exposure to acidic precipitation will cause the oxide to dissolve. In the zone of microchannel tube connection with the collector the situation is complicated by structural changes of metal and soldering flux residues, which locally disturb the passivation layer. That is why in real operating conditions, especially in urban and coastal regions, microchannel heat exchangers show pitting corrosion near the solder joint. This corrosion develops under the influence of moisture and contaminants, gradually destroying the wall and leading to leaks.

Lack of internal volume

A separate operational disadvantage is the lack of internal volume sufficient for refrigerant transfer during service work. A traditional condenser can condense most of the system refrigerant and hold it in the circuit for servicing. A microchannel condenser is not capable of performing this function, and a receiver is often not provided in microchannel designs. As a result, service crews are forced to evacuate the refrigerant completely during maintenance, and in emergency situations it is often necessary to vent it to the atmosphere, which increases the duration and cost of work and worsens environmental safety.

Repairability

While in a copper-aluminium heat exchanger it is possible to perform local repair, replace a section of the tube or braze a defective joint, a microchannel unit is virtually impossible to repair conventionally. Brazing aluminium requires precise temperature control and specialised flux, and overheating leads to destruction of the tube structure. As a result, even a minor leak in the collector area often renders the heat exchanger unrepairable on site and requires complete replacement. For large chillers, this means long downtime and high costs.

Figure 10-13 below provides a partial list of tube damage repairs to assess the labour cost of the process.

Fig. 10 – Damage to the cooling tube in the form of jamming

Fig. 11 – Blanking of the damaged tube. Determine the defective tube, make a hole with a knife on both sides of the tube

Fig. 12 – Muffling of the damaged tube. Before soldering, it is necessary to cover the cooling plates with a piece of sheet iron to avoid burning them out.

Fig. 13 – Deactivation of the damaged tube. View after soldering

This work requires a highly qualified soldererer and is extremely difficult to perform on site.

Thus, the design advantages of the microchannel heat exchanger simultaneously determine its system disadvantages. The minimum hydraulic diameter, low wall thickness, dense fin pattern and all-aluminium construction provide high efficiency, but create limitations in terms of reliability, fouling and corrosion resistance, and maintenance capabilities. It is these features that must be considered in the design and operation of equipment utilising microchannel condensers.

Conclusion

Microchannel capacitors are an efficient but technologically demanding design whose performance properties are directly determined by the geometry of the microchannels and the features of the all-aluminium architecture. The use of thin-walled extruded tubes makes it possible to significantly reduce the size of the unit, reduce the internal refrigerant volume and ensure high specific heat transfer. It is these qualities that made microchannel technology attractive to air chiller manufacturers and allowed its introduction into mass-produced equipment lines.

However, the design advantages also form system limitations. Dense fins and thin fins provide high thermal efficiency, but require careful cleaning and quickly lose performance when contaminated with air. The connection area between the microchannel tubes and the collector remains the most vulnerable part of the design and is prone to micro-cracking, especially when operating on refrigerants with higher condensing pressures. The corrosion resistance of aluminium is also limited in the actual operating environment, and the presence of residual fluxes and the influence of external factors accelerate the destruction of the oxide film.

For service organisations, the use of microchannel heat exchangers means altered maintenance methods. The inability to condense the entire volume of refrigerant in the heat exchanger and the absence of a receiver in most designs force complete evacuation of the refrigerant before any work. The repairability of such units is minimal: localised repair of defects is technically difficult and rarely gives a satisfactory result, which makes heat exchanger replacement a common solution.
